Feature
?Up to 1.25Gb/s bi-directional data links
?Compact RJ-45 connector
?Hot pluggable SFP footprint
?1Gigabit Ethernet over Cat 5 cable
?Applicable for 100m distance transmission
?Low power consumption, < 0.4W
?Access to physical layer IC via 2-wire serial bus
?1000 BASE-T operation in host systems with SERDES interface
?10/100/1000Mbps compliant in host systems with SGMII interface
?Operating case temperature:
?Commerical:0 to 70 °C
Applications
?Gigabit Ethernet 1000BASE-T
?Switch to Switch interface
?Switched backplane applications
?Router/Server interface
?Other optical transmission systems
