Product Features
?Supports up to 25.78Gb/s bit rates
?Duplex LC connector
?Hot pluggable SFP28 footprint
?850nm VCSEL transmitter, PIN photo-detector
?Distance up to 100m @50 / 125 um OM4
?Distance up to 70m @50 / 125 um OM3
?Built-in dual CDR
?Low power consumption, < 1.2W
?Digital Diagnostic Monitor Interface
?Compliant with SFP28 Specification SFF-8402e
?Electrical interface compliant to SFF-8431
?Operating case temperature:
Commerical:0~70°C
Applications
?25.78Gb/s single lane 100GBE SR4
?25GBE
?Other Optical Link
Ordering Information
Part Number | Description |
SFP28-25G-SR | SFP+, up to 25.78Gb/s, 850nm, 70/100m over OM3/OM4, 0~70℃, |
