Product Features
?Supports up to 11.3Gb/s bit rates
?Duplex LC connector
?Hot pluggable SFP+ footprint
?850nm VCSEL transmitter, PIN photo-detector
?Up to 300m on 50/125um MMF(2000MHZ.KM)
?Low power consumption, < 1W
?Digital Diagnostic Monitor Interface
?Optical interface compliant to IEEE 802.3ae
?Electrical interface compliant to SFF-8431
?Operating case temperature:
Commerical:0~70°C
Applications
?10G Base-SR/SW at 10.3125G
v10G Fiber Channel
?Other optical links
Ordering Information
Part Number | Description |
FS-0850-F03 | SFP+,up to 11.3Gb/s, 850nm, 300m, 0~70℃, with Digital Diagnostic Monitor |
